Drum Pumps

Standard Pump is a premium manufacturer of Drum Pumps, and Metering Systems serving the Chemical, Sanitary and Automotive industries. As a leading pump manufacturer, Standard is known for our commitment to Quality, Safety and Innovation. All Standard Pump products adhere to stringent guidelines set forth by agencies such as Underwriter's Laboratories (UL), CSA, Demko, 3A, and FDA. Our products are available in a variety of materials ensuring a quality solution when pumping Corrosive Chemicals, Diesel Exhaust Fluid (DEF), Cosmetic Lotions, or Food Products.



Drum Pump Tubes



Polypropylene Pump Tubes

Tube set assembly is engineered to transfer corrosive acids and alkalies.
Max. Temp: 130° F (55° C)



PVDF Pump Tubes

Tube set assembly is engineered to transfer highly concentrated acids.
Max. Temp: 175° F (80° C)



CPVC Pump Tubes

Tube set assembly is engineered to transfer high temperature media as well as water treatment chemicals.
Max. Temp: 190° F (88° C)



Stainless Steel Pump Tubes

Tube set assembly is engineered for transferring flammable / combustible liquids as well as petroleum based media.
Max. Temp: 175° F (80° C)



Aluminum Pump Tubes

is engineered for transferring Non-Corrosive liquids such as Machining Lubricants and Light Oils.
Max. Temp: 175° F (80° C)



Lengths:

27" (700 mm ), 39" (1000 mm), 47" (1200mm), 60" (1500 mm), 72" (1800 mm).





Drum Pump Motors



SP-280P Series

Engineered for use in corrosive environments. Ideally suited for transferring acids and alkalies.

MODEL

ENCLOSURE

POWER

WATT

V.S.D.

lbs

(kg)

SP-280P

Open Drip Proof (IP44)

110-120V/1/50-60Hz

825

NO

9.0

(4,0)

SP-280P-V

Open Drip Proof (IP44)

110-120V/1/50-60Hz

825

YES

9.0

(4,0)

SP-280P-2

Open Drip Proof (IP44)

220-240V/1/50-60Hz

825

NO

9.0

(4,0)

SP-280P-2-V

Open Drip Proof (IP44)

220-240V/1/50-60Hz

825

YES

9.0

(4,0)



SP-ENC Series

Engineered for use in heavily corrosive environments or when aggressive fumes are present. Ideally suited for transferring concentrated acids and alkalies.

MODEL

ENCLOSURE

POWER

WATT

V.S.D.

lbs

(kg)

SP-ENC

TEFC (IP54)

110-120V/1/50-60Hz

825

NO

12.7

(5,7)

SP-ENC-V

TEFC (IP54)

110-120V/1/50-60Hz

825

YES

12.7

(5,7)

SP-ENC-2

TEFC (IP54)

220-240V/1/50-60Hz

825

NO

12.7

(5,7)

SP-ENC-2-V

TEFC (IP54)

220-240V/1/50-60Hz

825

YES

12.7

(5,7)



SP-400 Series

Standard’s Explosion Proof Drum Pump is a safe solution for transferring highly flammable /combustible liquids and meets the stringent safety requirements of the Chemical Processing Industry.

MODEL

ENCLOSURE

POWER

WATT

V.S.D.

lbs

(kg)

SP-410EX

Explosion Proof

110-120V/1/50-60Hz

230

NO

17

(7,7)

SP-420EX

Explosion Proof

220-240V/1/50-60Hz

600

NO

17

(7,7)



SP-A1

Engineered for use in heavily corrosive environments or
when aggressive fumes are present. Ideally suited for transferring flammable / combustible liquids.



MAXIMUM



SHIPPING WT

MODEL

CONSUMPTION

INLET PRESSURE

OUTPUT

lbs

(kg)

SP-A1

22 CFM @ 90 psi

100 psi

1/2 HP

2.7

(1,2)



10.4 L/sec @ 6,2 bar

6,8 bar

370 W





SP-A2 Series

Engineered for use in heavily corrosive environments or when aggressive fumes are present. Ideally suited for transferring flammable / combustible liquids

MODEL

CONSUMPTION

INLET PRESSURE

SP-A2

28 CFM @ 90 psi

100 psi

OUTPUT

lbs

(kg)



13.2 L/sec @ 6,2 bar

6,8 bar

3/4 HP

3.4

(1,5)

SP-A2L

28 CFM @ 90 psi

100 psi

560 W



(trigger lock)

13.2 L/sec @ 6,2 bar

6,8 bar

3/4 HP

3.4

(1,5)
